Skontrolujte rozmery a špecifikáciu potrubia Duplex 2205 podľa ASTM A789/ A789M S31803, S32205
| 13.72 | 1.65 | 1/4 | 10S | 0.50 |
| 13.72 | 2.24 | 1/4 | 40S | 0.64 |
| 13.72 | 3.02 | 1/4 | 80S | 0.81 |
| 17.15 | 1.65 | 3/8 | 10S | 0.64 |
| 17.15 | 2.31 | 3/8 | 40S | 0.86 |
| 17.15 | 3.20 | 3/8 | 80S | 1.12 |
| 21.34 | 2.11 | 1/2 | 10S | 1.02 |
| 21.34 | 2.77 | 1/2 | 40S | 1.29 |
| 21.34 | 3.73 | 1/2 | 80S | 1.65 |
| 26.67 | 2.11 | 3/4 | 10S | 1.30 |
| 26.67 | 2.87 | 3/4 | 40S | 1.71 |
| 26.67 | 3.91 | 3/4 | 80S | 2.23 |
| 33.40 | 2.77 | 1 | 10S | 2.13 |
| 33.40 | 3.38 | 1 | 40S | 2.54 |
| 33.40 | 4.55 | 1 | 80S | 3.29 |
| 33.40 | 6.352) | 1 | 160 | 4.30 |
| 42.16 | 2.77 | 1¼ | 10S | 2.73 |
| 42.16 | 3.56 | 1¼ | 40S | 3.44 |
| 42.16 | 4.85 | 1¼ | 80S | 4.53 |
| 42.16 | 6.352) | 1¼ | 160 | 5.69 |
| 48.26 | 2.77 | 1½ | 10S | 3.16 |
| 48.26 | 3.68 | 1½ | 40S | 4.11 |
| 48.26 | 5.08 | 1½ | 80S | 5.49 |
| 60.33 | 2.77 | 2 | 10S | 3.99 |
| 60.33 | 3.91 | 2 | 40S | 5.52 |
| 60.33 | 5.54 | 2 | 80S | 7.60 |
| 60.33 | 8.742) | 2 | 160 | 11.29 |
| 73.03 | 3.05 | 2½ | 10S | 5.35 |
| 73.03 | 5.16 | 2½ | 40S | 8.77 |
| 73.03 | 7.01 | 2½ | 80S | 11.59 |
| 88.90 | 3.05 | 3 | 10S | 6.56 |
| 88.90 | 5.49 | 3 | 40S | 11.47 |
| 88.90 | 7.62 | 3 | 80S | 15.51 |
| 88.90 | 11.132) | 3 | 160 | 21.67 |
| 101.60 | 3.05 | 3½ | 10S | 7.53 |
| 101.60 | 5.74 | 3½ | 40S | 13.78 |
| 101.60 | 8.08 | 3½ | 80S | 18.92 |
| 114.30 | 3.05 | 4 | 10S | 8.50 |
| 114.30 | 6.02 | 4 | 40S | 16.32 |
| 114.30 | 8.56 | 4 | 80S | 22.67 |
| 114.30 | 13.492) | 4 | 160 | 34.05 |
| 141.30 | 6.55 | 5 | 40S | 22.10 |
| 141.30 | 9.53 | 5 | 80S | 31.44 |
| 141.30 | 15.882) | 5 | 160 | 49.87 |
| 168.28 | 3.4 | 6 | 10S | 14.04 |
| 168.28 | 7.11 | 6 | 40S | 28.69 |
| 168.28 | 10.97 | 6 | 80S | 43.21 |
| 168.28 | 14.27 | 6 | 120 | 54.75 |
| 168.28 | 18.262) | 6 | 160 | 68.59 |
| 219.08 | 8.18 | 8 | 40S | 43.20 |
| 219.08 | 12.7 | 8 | 80S | 65.63 |
| 219.08 | 18.23 | 8 | 120 | 91.30 |
| 219.08 | 23.012) | 8 | 160 | 112.97 |
2205 Schéma plánovania duplexných potrubí
| 1/8" IPS (.405" vonkajší priemer) | 3 1/2" IPS( 4.{3}"OD) |
|---|---|
| SCH 40, 80 | SCH 10%, 40%, 80%, 160%, XXH |
| 1/4" IPS (.540" vonkajší priemer) | 4" IPS (4 500" vonkajší priemer) |
| SCH 10%, 40%, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8" IPS (0,675" vonkajší priemer) | 5" IPS (5,563" vonkajší priemer) |
| SCH 10%, 40%, 80 | SCH 10%, 40%, 80%, 160%, XXH |
| 1/2" IPS (0,840" vonkajší priemer) | 6" IPS (6,625" vonkajší priemer) |
| SCH 5%, 10%, 40%, 80%, 160%, XXH | SCH 5%, 10%, 40%, 80%, 120%, 160%, XXH |
| 3/4" IPS (1,050" vonkajší priemer) | 8" IPS (8,625" OD) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS: (1,315′OD) | 10" IPS (10,750" vonkajší priemer) |
| SCH 5%, 10%, 40%, 80%, 160%, XXH | SCH 10, 20, 40, 80 (0,500), TRUE 80 (,500) |
| 1-1/4" IPS (1,660" OD) | 12" IPS (12,750" vonkajší priemer) |
| SCH 10%, 40%, 80%, 160%, XXH | SCH 10, 20, 40 (0,375), TRUE40 (,406), SCH80 (,500) |
| 1-1/2" IPS (1 900" OD) | 14" IPS (14.{2}"OD) |
| SCH 10%, 40%, 80%, 160%, XXH | SCH10 (0,188), SCH40 (0,375) |
| 2" IPS (2,375" OD) | 16" IPS (16.{2}"OD) |
| SCH 10%, 40%, 80%, 160%, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2" IPS (2,875" OD) | 18" IPS (18.{2}"OD) |
| SCH 10%, 40%, 80%, 160%, XXH | SCH-40 (0,375) |
| 3" IPS (3 500" vonkajší priemer) | |
| SCH 5, 10, 40, 80, 160, XXH |
